| Model |
MV1750S |
| Travel |
|
X axis travel |
1750(68) |
| Y axis travel |
900(35) |
| Z axis travel |
760(30) |
| Spindle nose to table |
200-960(7.8-37.7) |
| Table |
|
| Table height |
925(36.4) |
| T solt size |
7-18Tx125 |
| Table Max.load |
2000(4400) |
| Table size |
2000x880(78x34.6) |
| Feedrate |
|
| X/Y/Z Rapid traverse |
18/18/12 |
| X/Y/Z Feed rate |
1-5 |
| X/Y/Z Servo power |
7(9.4) |
| ATC |
|
| NO. of tools |
32 |
| Max. tool weight |
8 |
| Max. tool Dia ( No adjacent) |
150 |
| Spindle |
|
| Spindle speed |
10000 |
| Spindle taper |
#40 |
| Spindle motor |
18.5/22(25/30) |
| General |
|
| Weight |
≒15000(33300) |
| Power capacity |
25 |
| Pneumatic source requirement |
|
|
